As a specialist of EPS/Rockwool Sandwich Panel Machine , Jingshirui can offer you comprehensive selections of goods in this industry
Technical Details
| Machine Specifications | |
|---|---|
| Weight | About 21000kgs |
| Whole line’s dimension | About 40m x 3.0m x2.5m (length x width x height) |
| Color | Main color: blue |
| Warning color: yellow | |
| Inner Core Material | |
| Polystyrene (EPS) | Block-shape |
| Rockwool | Strips |
| Outer Skin Material | |
| Thickness | 0.3-0.7mm |
| Coil width | 1200mm |
| Material | Galvanized steel coils |
| Yield Strength | 235Mpa |
| Main Technical Parameters | |
| Production speed | EPS Sandwich Panels: 3-5m/min |
| Rockwool Sandwich Panels: 1.5-2.5m/min | |
| Controlling system | PLC and Converter |
| Electric power | About 30kw totally |
| Electric voltage | 380V/3Phase/50HZ or as per clients requirement |
| Air pressure | 0.7Mpa (for buyer to prepare air compressor) |
| Suitable working temperature | Around 25 degree |
| Main Components | |
| Decoiler (manual and automatic for options) | 1 set |
| Roll Forming machine | 1 set |
| EPS Feeding table | 1 set |
| Heating device | 2 sets |
| Laminator system | 1 set |
| PLC control box | 1 set |
| Cutting unit | 1 set |
| Run racks tables | 1 set |
