this CZ purlin machine make CZ size from 100mm to 355mm, that is 4 inch to 14 inch, height to 10omm or 4 inch.
standard size for CZ , size from80-300mm, height 40-80mm
Suitable raw material for c&z purlin roll former
1 ) Suitable Raw Materials: galvanized steel sheet,hot rolled material, cold rolled material
2 ) Coil Width:according to your size
2 ) Suitable Coil Thickness: 1.5mm -3.0mm
4) Yield strength of raw material: 235-345Mpa
Main parameters of cz purlin roll forming machine
1) Forming Speed: 0-20m/min. (excluding the cutting time)
2) Main Motor Power: 15KW (Depend on final design)
3) Hydraulic Station Power: 5.5KW (Depend on final design)
4) Control System: Mitsubishi or siemens PLC and transducer (Japan)
5) Encoder: Nemicon (Japan)
6) Rollers’ material GR15 Steel with quench treatment
7) Shaft diameter 75mm, tooled by grinding machine for two times
to ensure the precision of final product.
8) Type of Cutting: Length-set cutting and post forming style
9) Electric Condition: 460V/3Phase/60HZ(oraccording to customer)
10) Total Weight: About 9500 Kg
Main components of purlin forming machine
(1) Manual decoiler 1 set（Capacity : 5 tons）hydraulic decoiler is available with additional cost
(2) Roll-Forming M/C 1 set
(3) Hydraulic punch and Cutting 1 set
(4) Hydraulic station 1 set
(5) PLC Control System 1 set
(6) run out table 1 set
