Argentina customer buy T 101 roll forming machine and sinusoidal machine and C purlin machine, he send one technician to our factory to test machines quality.
the customer is satisfied with our roll forming machines, when the production requirement increase, they buy us another two same roll formers.
popolar roofing design in Argentina
conformado sinusoidal -900
conformado sinusoidal -1100
conformado trapezoidal T 101
conformado trapezoidal T 90
Technical Details
| Machine Specifications | |
|---|---|
| Weight | About 7500kgs |
| Size | About 10m x 1.7m x 1.5m (length x width x height) |
| Color | Main color: blue |
| Warning color: yellow | |
| Suitable Raw Material | |
| Material | Colored Steel Coils |
| Thickness | 0.3-0.7mm |
| Coil width | 960mm |
| Yield Strength | 550Mpa |
| Main Technical Parameters | |
| Quantity of forming rollers stations | 20-22 |
| Diameter of forming rollers shafts | 75mm |
| Roll Forming Speed | 15-20m/min |
| Forming rollers material | No.45 steel, coated with chromed treatment |
| Cutter material | CR12 mould steel, with quenched treatment |
| Controlling system | PLC and Converter |
| Electric Power requirement | Main motor power: 7.5kw |
| Hydraulic unit motor power: 3kw | |
| Electric voltage | According to customer’s requirement |
